RE-201D Rotary Evaporator
RE-201D rotary evaporator is a small volume rotary evaporator , it is heated by water bath(oil bath) to form thin film under the negative pressure condition, evaporate highly, then condense and recycle the solvent simultaneously.RE-201D rotary evaporator is particularly suitable for the heat-sensitivity material’s condensation, separation, crystallization, recovery and so on. It is one of the commonly used tools in the chemical industry, the pharmaceutical industry, universities and research laboratories,etc.
RE-201D rotary evaporator features:
1. Quick and easy lifting mechanism.
RE-2000 rotary evaporator includes:RE-2000A rotary evaporator,RE-2000B rotary evaporator,RE-2000E rotary evaporator.
2. The evaporator can be tilted horizontally in the range of 0-45°.
3. High evaporation rate of the vertical condensation system.
The condenser adopts two structures. One is the dual pipeline convection principle and is used for evaporating organic solvents. The other is single pipe container with interlayer that could hold cooling water, ice and Didrikson. It is vertical type to decrease volume and is used for evaporating organic solvents.
4. PTFE evaporating pipe,and Fluorine rubber mat make good sealing performance.
5. Automatic temperature control digital display.
6. GG-17 high borosilicate glass evaporating flask and receiving flask.
7. 110 V/60HZ can be customized.
| Model | RE-201D |
| Rotating Flask（L） | 2 |
| Collection Flask（L） | 1 |
| Rotating Motor（W） | 40 |
| Rotating（R/min） | 0-120 |
| Water（Oil）Bath Power（W） | 1200 |
| Temp Control Mode/Range（℃） | RT-399 |
| Temp Resolution（℃） | ±2 |
| Evaporation Rate（L/H2O） | ≥1 |
| Max Vacuum Degree | ＜133pa |
| Lifting Height(mm) | 0-150 |
| Water Bath Size(mm) | Φ24*15 |
| Condenser | Vertical with charge pipe，Large Condenser，evaporating pipe |
| Lifting Mode | Oil bath Manual Lifting |
| Voltage | 220V/50HZ |
| Sealing Mode | PTFE，fluoro rubber sealing |
