The rotary evaporator produced by ZZKD has a reasonable structure, and the mechanical part is made of stainless steel and aluminum alloy. All glass parts are made of corrosion-resistant, high-temperature resistant borosilicate glass. Rubber seals comply with international standards and are easy for users to purchase and replace.Below is the schematic diagram of glass assembly.

1.Upright
2.Cross clip
3.Vacuum table fixing rack
4.Condenser clamp fixing seat
5.Silicone rubber band
6.Flange gasket
7.Flange gasket
8.Flange gasket
9.Three bottles
10.Feed piston
11.PTFE tube
12.Flange gasket
13.a main condenser
14.Flange gasket
15.Auxiliary condenser
16.Condenser tray
17.Recovery bottle
18.Recovery bottle tray
19.Discharge valve
20.Cross clip
21.Flange gasket
22.Vertical rod joint
23.Cross clip
24.Flange gasket
25.Cross clip
26.Glass elbow
27.Flange gasket



The rotary evaporator equipment we supply includes: low temperature cooling liquid circulating pump, circulating water vacuum pump. Explosion-proof devices can be installed(explosion proof rotary evaporator) according to customer requirements, please feel free to consult.
